12V 15A 24V 10A 8 AA EV Battery Charger Lithium Ion 360W Rechargeable
Product Details:
| Place of Origin: | China |
| Brand Name: | Alrightpower |
| Certification: | UL,FCC,CB,CE,UKCA,CCC,PSE,KC,RCM etc |
| Model Number: | AP-PN360 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 500PCS |
|---|---|
| Packaging Details: | Individul Pe Bag Packing or others |
| Delivery Time: | 30 working days |
| Payment Terms: | T/T, Western Union |
| Supply Ability: | 50000PCS/Day |
|
Detail Information |
|||
| Input: | 100-240V 50/60HZ | Output: | 360W Max |
|---|---|---|---|
| Material: | ABS+PC | Color: | Black, White Or Others |
| Protection: | OCP, OLP, OVP And Others | Logo: | Fullpower Or Custom Made |
| High Light: | 12V 15A EV Battery Charger,360W EV Battery Charger,Rechargeable 8 AA Battery Charger |
||
Product Description
360W Lithium Ion Battery Charger 8 AA Battery Charger Rechargeable Battery Charger
• Max Output Power: 360W
• Typical output: 12V15A, 24V10A, 36V7A,48V6A, etc
• UL,FCC,CE,CB, UKCA, KC, PSE, CCC, etc Certifications
• Meet very high efficiency standards
• Custome make DC connector
|
Shenzhen YingYuan Electronics Co., Ltd Address:The 4-7th Floor, Building 8, HongYe Industrial Park, XiXiang Town, BaoAn District, ShenZhen, China |
||||
| Specifications | PRODUCTS PICTURE | |||
|
360W BATTERY CHAEGER l AC Input Voltage Range:AC100V～AC240V l AC Input Frequency: 45～65HZ l AC Power Factor Correction: ≥0.98 l Output Voltage:12V～60V l Output Current:15A(Max) l Full Load Efficiency: ≥90% l Shock & Vibration: 10～50HZ 2G 10 minutes,X,Y,Z /60 minutes l Operating Temperature: -20ºC～+45ºC(-20ºF～+113ºF) l Storage Temperature: -40ºC～+85ºC(-40ºF～+185ºF) l Dimensions (mm):(L)183х(W)122.5х(H)69 l Net Weight: 2kg |
 |
|||
| TYPICAL MODEL LIST | ||||
| Charger Model | Rated Input Voltage | Battery Standard Voltage | Maximum charging Current | Maximum charging Current |
| AP-PN360CH01460150 | 100-240 | 12 | 14.6 | 15 |
| AP-PN360CH02920100 | 100-240 | 24 | 29.2 | 10 |
| AP-PN360CH04200070 | 100-240 | 36 | 42 | 7 |
| AP-PN360CH05460060 | 100-240 | 48 | 54.6 | 6 |
| AP-PN360CH01200150 | 100-240 | 12 | 14.6 | 15 |
| AP-PN360CH02400100 | 100-240 | 24 | 29.2 | 10 |
| AP-PN360CH03600070 | 100-240 | 36 | 42 | 7 |
| AP-PN360CH04800060 | 100-240 | 48 | 54.6 | 6 |
| SPECIFICATIONS | ||||
| AC Input Voltage Range: | AC100V～AC240V | Shock & Vibration: | 10～50HZ 2G 10 minutes,X,Y,Z /60 minutes | |
| AC Input Frequency: | 45～65HZ | Operating Temperature: | -20ºC～45ºC(-20ºF～+113ºF) | |
| AC Power Factor Correction: | ≥0.98 | Storage Temperature: | -40ºC～+85ºC(-40ºF～185ºF) | |
| Output Voltage: | 12V～60V | Dimensions (mm): | (L)183х(W)122.5х(H)69 | |
| Output Current: | 15A(Max) | Net Weigh: | 2kg | |
| Full Load Efficiency: | ≥90% | Certifications | UL CE FCC RoHs | |
| Protections |
Thermal Self-Protection Charger will be stopped automatically when reaches to Maximum temperature , LED light will be red to warn it |
|||
|
Short- circuit Protection When Short Circuit happened ,charger will turn off |
||||
|
Reverse Connection Protection When the battery is polarity reversed ,the charger will cut off the connection between the circuit and the battery |
||||
|
Battery Broken protection When some battery broke ,battery can not reach 100% full-charged ,charger will be shut down automatically |
||||
| Application | Forklift/ground washer/electric motorcycle and so on | |||
| MECHANICAL SPECIFICATION | PACKING DETAILS | |||
|
2kg/pcs 12pcs/Carton Carton size: 580*480*185mm
|
|||
This product has different charging modes basic on different types battery and can trace the charging process correctly.
Main application of charger: e-bike, e-scooters, forklift, Delivery robot, ground washer, electric motorcycle, golf cart, low speed car and so on.
